Foot Master

SGDN-60-F-NYN

SGDN-60-F-NYN

SKU:SGDN-60-F-NYN-STAINLESS-STEEL

Enquire Now
* Brackets: Stainless forged steel plate and stainless casting frame, double ball bearing with hardened stainless steel bearing seats in the swivel head, height adjustment with integrated orange handle or spanner, anti-vibration NBR pad, bolted wheel axle structure, completely corrosion-resistant components applied
* Surface Treatment: Electrolytic polishing
* Wheel: Nylon66(Shore D70), no bearing

● Model
ㆍSGDN-60-F-NYN
View full details
Wheel Diameter50 mm
Width of Tread25 mm
Hardness of Tread70 Shore D
Size of Plate73 x 73 mm
Plate Hole Centers58 x 58 mm
Plate Hole7 mm
Leveling Extent10 mm
Offset38 mm
Overall Height82 mm
Temperature-10 ~ +90 ℃
Load Capacity / 1pcs280 kg
Load Capacity / 4pcs560 kg
