Foot Master

PL-75-ASS/BSS-EUS

PL-75-ASS/BSS-EUS

SKU:PL-75-ASS-BSS-EUS-NOISE-FREE-ELASTIC

Enquire Now
* Brackets: Forged steel bolt, precision ball bearing in the swivel head which is advantageous to smooth swiveling and excellent durability, strong integrated pressed steel frame, total-lock top brake system which is applied in wheel and swivel head simultaneously with independent locking and unlocking lever, bolted wheel axle structure,
* Surface Treatment: Powder coating, zinc plated
* Wheel: High elasticity polyurethane(Shore A80), PC core, one ball bearing
● Model
ㆍPL-75-ASS-EUS(Swivel)
ㆍPL-75-BSS-EUS(Swivel with brake)
View full details
Wheel Diameter75 mm
Width of Tread25 mm
Hardness of Tread80 Shore A
Center Bolt5/8 "-11UNC or M12x1.75P or 1/2 "-12UNC
Bolt Length25 mm
Offset40 mm
Overall Height112.5 mm
Temperature-10 ~ 90 ℃
Load Capacity / 1pcs75 kg
Load Capacity / 4pcs225 kg
