| Wheel Diameter | 63 mm |
| Width of Tread | 28 mm |
| Hardness of Tread | 70 Shore D |
| Center Bolt | M12 x 1.75P or M16 x 2.0P |
| Bolt Length | 16 mm |
| Leveling Extent | 15 mm |
| Offset | 46 mm |
| Overall Height | 103 mm |
| Temperature | -10 ~ +90 ℃ |
| Load Capacity / 1pcs | 550 kg |
| Load Capacity / 4pcs | 1,100 kg |
※ The NBR pad may be deflected by the load a bit.
