| Wheel diameter | D | 175 mm |
| Tyre width | E | 40 mm |
| Outer faces bearings distance | V | 44 mm |
| Overall height | H | 215 mm |
| Top plate outer dimensions | AxB | 135x110 mm |
| Bolt hole spacing | axb | 105x75 mm |
| Bolt hole spacing | axb | 105x80 mm |
| Fixing bolt diameter | g | M10 |
| Offset | F | 57 mm |
| Load Capacity | 300 kg |
