| Wheel diameter | D | 125 mm |
| Tyre width | E | 30 mm |
| Outer faces bearings distance | V | 38 mm |
| Overall height | H | 159 mm |
| Top plate outer dimensions | AxB | 135x110 mm |
| Bolt hole spacing | axb | 96x56 mm |
| Bolt hole spacing | axb | 105x75 mm |
| Bolt hole spacing | axb | 105x80 mm |
| Fixing bolt diameter | g | M10 |
| Offset | F | 49 mm |
| Load Capacity | 200 kg |
