LAG

WHEEL DG 200X50/60 NYLON PLAIN BORE SWIVEL FORK M22

Name: WHEEL DG 200X50/60 NYLON PLAIN BORE SWIVEL FORK M22
Brand: LAG
SKU: 13936G
Availability: InStock

SKU:13936G

Wheels with elastic grey rubber ring on a thermoplastic core, with standard or stainless steel roller bearings or nylon friction bearings.The wheel is fitted with bushes.

View full details

Wheel diameter	D	200 mm
Tyre width	E	50 mm
Overall height	H	240 mm
Top plate outer dimensions	AxB	135x110 mm
Bolt hole spacing	axb	105x75 mm
Bolt hole spacing	axb	105x80 mm
Fixing bolt diameter	g	M10
Offset	F	59 mm
Load Capacity		230 kg
